Ez-Pi +

SKU: 3600 Category:

EZ-PI Plus is a small research oriented tensiometer equipped with a very high resolution sensor.

11 470,00

A versatile force tensiometer

Kibron EZ-PI Plus was designed and built with reliability and ease of use in mind. EZ-PI Plus is compact size, and easy to move. State-of-the-art sensor technology with excellent resolution, connection for water bath, and intuitive user interface.

Accurate and fast surface and interfacial tension measurements

  • A high precision instrument for research
  • Surface tension, oil/water interfacial tension, and contact angle measurements
  • Measures samples with high viscosity (Wilhelmy technique combined with small diameter probe). Currently tested to 100 000 mPas (Newtonian),
  • An easy to use tensiometer for educational purposes, no special training needed
  • An ideal instrument for the metal plating industry
  • Excellent for oil refineries for the monitoring of sour water
  • ASTM D 1331 – 14

Contact angle measurements

  • Advancing and receding contact angle
  • Wetting measurements of single fibers, for example textile, hair and reinforcement fibers down to 1 µm diameter
  • Connects to water bath for temperature control


Product code Description
#3601 EZ-Pi Plus -instrument
#1511 Interface cable, USB
#3523 Sample cup, set of 10 pcs
#1500 Set of DyneProbes, 4 pcs
#6999 Pt-100 Temperature sensor
#3625 EZ-Pi Plus Manager -software and Users guide on a USB pen drive
#3524 Carrying case


Principle of operation: minituarized Du-Noüy/ Wilhemly
Measuring range: 1-350 mN/m
Accuracy/sensitivity: 0.01 mN/m
Resolution: 0.001 mN/m (0.2 µg) for 0-100 mg sensor and 0.003 mN/m (0.6 µg) for 0-300 mg sensor
Sample cup material: Polypropylene / Glass / Teflon
Sample volume: 0.5-3 ml std (stainless steel vial 25 – 50 microliter available on request )
Maximum viscosity: 60 000 cP (Newtonian)
Weight: 1.3 kg
Dimensions: 26 x 8 x 16 cm (10.2 x 3.1 x 6.3 in)
Average time per measurement: Around 30 seconds
Temperature control 0-100 °C, connects to circulating bath
Power/communication: Power is supplied through the same USB port used for communication
